Ford 300 LS1-6 Empty Ford 300 LS1-6

Post  512Fairlane December 25th 2011, 1:32 am

OK I know this isn't a big block Ford and it does involve some parts from a brand-x vehicle but I think some of you will appreciate the back yard engineering involved. Dad is adding a LS1 Chebbie head to his 300 Ford six. He cut one cyliinder off each head and epoxied the two heads together. He is building his own steel sheet metal manifold for 3 Holley two barrels along with some 1 3/4 to 1 7/8 step headers. He has about $300.00 bucks in his aluminum head so far.

http://www.flickr.com/photos/512fairlane/sets/72157628557600461/


Last edited by 512Fairlane on December 25th 2011, 1:07 pm; edited 1 time in total
512Fairlane
512Fairlane

Posts : 694
Join date : 2009-08-19
Location : Mid Missouri

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  res0rli9 December 25th 2011, 2:02 am

Ive seen that done with Boss 302 heads back in late 60s early 70s

res0rli9
BBF CONTRIBUTOR
BBF CONTRIBUTOR

Posts : 3351
Join date : 2008-12-02
Age : 74
Location : sarasota FL.

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  schmitty December 25th 2011, 10:03 am

Cool project, true hot rod spirit there. cheers Not to be too nit picky, but it doesn't look like the valve cover fits quite right. Laughing
schmitty
schmitty

Posts : 4538
Join date : 2008-12-02
Age : 53
Location : Holdrege, NE

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  Curt December 25th 2011, 10:12 am

schmitty wrote:Cool project, true hot rod spirit there. cheers Not to be too nit picky, but it doesn't look like the valve cover fits quite right. Laughing

I'm with Rob on this! My engine builders would have a fit if the oil got dirty! Laughing


Ford 300 LS1-6 Bob-The-Builder
Curt
Curt

Posts : 2787
Join date : 2009-02-08
Age : 61
Location : Henrietta, Texas but mostly on the road

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  512Fairlane December 25th 2011, 10:20 am

schmitty wrote:Cool project, true hot rod spirit there. cheers Not to be too nit picky, but it doesn't look like the valve cover fits quite right. Laughing

Yeah he's still trying to find the best way to stretch those covers. They have to be the ugliest valve covers ever made.
512Fairlane
512Fairlane

Posts : 694
Join date : 2009-08-19
Location : Mid Missouri

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  '65 T-BOLT December 25th 2011, 11:38 am

pure hotrod ingenuity !!! I wish your dad was my dad!
'65 T-BOLT
'65 T-BOLT

Posts : 1464
Join date : 2009-08-28
Age : 53
Location : Hagerstown,Maryland

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  jbozzelle December 25th 2011, 5:30 pm

Sweet. Pure hot ridding there. Will he weld the heads together?

jbozzelle

Posts : 3705
Join date : 2009-08-10
Age : 49
Location : New Orleans

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  512Fairlane December 25th 2011, 7:17 pm

jbozzelle wrote:Sweet. Pure hot ridding there. Will he weld the heads together?

No he had the heads machined after they were cut. Then he epoxied in some aluminum plates to seal the water jackets off between the heads. He drilled a couple of holes in the plate on each head for water to travel between the two halves. This left a large surface area to epoxy together. They are stuck together very well. The epoxy is a high temp. type so I guess it will work. We'll find out.
512Fairlane
512Fairlane

Posts : 694
Join date : 2009-08-19
Location : Mid Missouri

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  bbf-falcon December 26th 2011, 9:51 pm

Interesting read.
http://www.maverick.to/mmb/showthread.php?t=31791&highlight=preperation&page=4

bbf-falcon

Posts : 8995
Join date : 2008-12-03
Location : Jackson, Ohio

Back to top Go down

Ford 300 LS1-6 Empty More pics

Post  512Fairlane February 12th 2012, 11:03 pm

Made it out to the old man's today to check progress. It's coming along. Here are some pics of the headers and start of the intake.

http://www.flickr.com/photos/512fairlane/sets/72157629294140249/
512Fairlane
512Fairlane

Posts : 694
Join date : 2009-08-19
Location : Mid Missouri

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  dfree383 February 13th 2012, 12:00 am

Way cool project.
dfree383
dfree383
BBF CONTRIBUTOR
BBF CONTRIBUTOR

Posts : 14772
Join date : 2009-07-09
Location : Home Wif Da Wife.....

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  83-88T-Bird Guy February 13th 2012, 9:05 am

Definitely cool !
83-88T-Bird Guy
83-88T-Bird Guy

Posts : 1003
Join date : 2008-12-03
Age : 109
Location : Bardstown, KY

Back to top Go down

Ford 300 LS1-6 Empty Ford 300 6 with LS1 Head

Post  512Fairlane February 1st 2014, 1:43 am

I realized I never finished this post. Dad did get the hybrid 300 6 with ls1 head running and it made it down the track. He battled some issues at first that turned out to be totally unrelated to the swap. He couldn't get it to pull over 5000 RPM. We thought we had something wrong with the combo but it turned out the MSD 2 step had quit working. Also had some water sealing problems with the seal between the two heads. He had a few valvetrain issues but we think we have all of that worked out. Currently the head is back off to address the sealing problems. The Ford head is back on it now but we hope to get this head back on. If nothing else it looks freakin' awesome.

http://www.flickr.com/photos/512fairlane/sets/72157640375802193/
512Fairlane
512Fairlane

Posts : 694
Join date : 2009-08-19
Location : Mid Missouri

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  61coon February 1st 2014, 8:50 am

Very cool project!!! Can't say I've ever seen that done before. Hopefully he'll get the sealing problem fixed. I like it man!!! Cool
61coon
61coon

Posts : 1824
Join date : 2009-08-07
Age : 46
Location : Hillsboro,TN

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  bbf-falcon February 1st 2014, 8:54 am

Cool Very Happy

bbf-falcon

Posts : 8995
Join date : 2008-12-03
Location : Jackson, Ohio

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  LivermoreDave February 1st 2014, 11:16 am

I must commend your Dad's efforts and his work ethic. That's an interesting project. I like the idea, I think the older style A3, B3 or C3 heads would have been my choice. I say that because I simply could not perform the fabrication required your Dad has. Great job!

Dave.

LivermoreDave

Posts : 972
Join date : 2009-09-27
Location : North of the Equator.

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  512Fairlane February 1st 2014, 4:22 pm

Dave I agree that it would be cool to have one of the Ford style heads on there but there are actually some advantages to using the Chevy head. The valves on the 300-6 are reversed from a sbf. The Chevy head has the same valve orientation as the 300 so it does not require a special cam. The bore spacing was close enough that he only had to cut one cylinder off of each head and center the middle cylinder on the block. Plus these heads are dirt cheap and we don't feel bad about cutting up a good Ford head Very Happy .
512Fairlane
512Fairlane

Posts : 694
Join date : 2009-08-19
Location : Mid Missouri

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  Tommyj466 February 1st 2014, 6:07 pm

That is so cool! I bet it sounds pissed off!

TJ
Tommyj466
Tommyj466

Posts : 322
Join date : 2009-01-06
Location : Versailles Ky

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  512Fairlane February 1st 2014, 8:07 pm

Its amazing how much different it sounds with the better flowing head. It used to sound like a tractor at idle. Now it sounds like a small block Ford. Still sounds like a swam of bumble bees at 5000 RPM though. He ran about the same as the Ford head but it was nosing over at 5000 on the rev limiter. Can't wait till he can let it rev.
512Fairlane
512Fairlane

Posts : 694
Join date : 2009-08-19
Location : Mid Missouri

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  Mike R February 1st 2014, 11:57 pm

Now that's thinking outside the box, A cool project and a lot of fun engineering it and putting it together. Can't wait to see it run cheers cheers cheers

Mike R

Posts : 1381
Join date : 2009-08-05
Age : 63
Location : St Paul Mn

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  512Fairlane February 2nd 2014, 10:35 am

80 Fairmont wagon with a 528? Any pics of that? I love the Fairmonts.
512Fairlane
512Fairlane

Posts : 694
Join date : 2009-08-19
Location : Mid Missouri

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  Mike R February 2nd 2014, 10:26 pm

I'll have to have one of my kids help me post some

Mike R

Posts : 1381
Join date : 2009-08-05
Age : 63
Location : St Paul Mn

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  BigBlockRanger February 15th 2014, 11:42 pm

This made the Bangshift blog!

http://bangshift.com/blog/mad-science-a-drag-racer-sliced-and-diced-a-pair-of-ls-heads-stuck-them-together-and-mounted-them-on-a-ford-inline-six.html
BigBlockRanger
BigBlockRanger

Posts : 1188
Join date : 2008-12-02
Age : 53
Location : Amarillo

Back to top Go down

Ford 300 LS1-6 Empty Re: Ford 300 LS1-6

Post  512Fairlane February 16th 2014, 9:01 pm

That's a pretty cool article. I'll have to let Dad know.
